G657A G652D Aerial Steel Wire GYXTW FTTH Fiber Optic Cable

Product Categories
Wuhan Weiruo Communication Tech. Co.,Ltd
Contact Now

G657A G652D Aerial Steel Wire GYXTW FTTH Fiber Optic Cable

Brand Name : Wrc-Single Mode G657A G652D GYXTW Aerial Outdoor Steel Wire Optical Fiber Cable FTTH GYXTW Fiber Optic Cable

Model Number : Single Mode G657A G652D GYXTW Aerial Outdoor Steel Wire Optical Fiber Cable FTTH GYXTW Fiber Optic Cable

Certification : ISO9001,SGS

Place of Origin : China

MOQ : 5.0km

Price : USD100-USD350/Km

Payment Terms : Western Union, MoneyGram, D/P, T/T, L/C

Supply Ability : 500Km per day

Delivery Time : 5-21 days

Packaging Details : Export Carton Packing

Application : Telecommunication,Telecom,Network

Fiber type : G652D,single mode or multi mode,50/125,62.5/125,OM3

Number of conductors : 2,4,8,24,48

Type : Single Mode g652d,Outdoor Optical Cable Aerial,Singlemode & Multimode

Fiber count : 2-24 core

Color : Black,Blue,Grey,Customized,Green

Jacket : PE,MDPE,LSZH,PVC

Name : Single Mode G657A G652D GYXTW Aerial Outdoor Steel Wire Optical Fiber Cable FTTH GYXTW Fiber Optic Cable

Length : 2km , or customized length

Jacket material : PE,LSZH,TPU,LSZH OR PVC

Oem : Available

Installation : self- supporting Aerial,aerial, Duct

Structure : Loose tube,Unitube

Operating temperature : -40~75

Sheath material : LSZH,HDPE,PVC

Strength member : steel wire

Fiber color : Blue,Orange,Brown,Aqua,Grey,Customized

Contact Now

Description: Single Mode G657A G652D GYXTW Aerial Outdoor Steel Wire Optical Fiber Cable FTTH GYXTW Fiber Optic Cable

GYXTW single-mode/multimode fibers are positioned in the loose tube, which is made of high modulus plastic materials
and filled with filling compound. PSP is longitudinally applied around the loose tube, and water-blocking materials
are distributed into interstices between them to guarantee the compactness and longitudinal water-blockingperformance.

Two parallel steel wires are placed at both sides of the cable core while PE sheath is extruded over it.

Characteristics of Single Mode G657A G652D GYXTW Aerial Outdoor Steel Wire Optical Fiber Cable FTTH GYXTW Fiber Optic Cable
1. Good mechanical and temperature performance
2. High strength loose tube that is hydrolysis resistant
3. Special tube filling compound ensure a critical protection of fiber
4. Crush resistance and flexibility
5. The following measures are taken to ensure the cable watertight:
6. Loose tube filling compound, 100% cable core filling
7. PSP/PAP enhancing moisture-proof
8.Steel wire used as the central strength member

Structure and Technical specifications of Single Mode G657A G652D GYXTW Aerial Outdoor Steel Wire Optical Fiber Cable FTTH GYXTW Fiber Optic Cable

Fiber Count

(F)

Cable Diameter

(mm)

Cable Weight

(kgs)

 Tensile Strength (N) Crush Strength (N) Min. Bending Radius

Temperature Range

(℃)
Long term Short Term Long term Short Term Long term Short Term
2 8.0 78 600 1500 300 1000 10D 20D -40~+60
4 8.0 78 600 1500 300 1000 10D 20D -40~+60
6 8.0 78 600 1500 300 1000 10D 20D -40~+60
8 8.0 78 600 1500 300 1000 10D 20D -40~+60
10 8.0 78 600 1500 300 1000 10D 20D -40~+60
12 8.0 78 600 1500 300 1000 10D 20D -40~+60

We produce cables according to the standard as below:
Mechanical Performance
Max Tension Performance IEC 60794–1-2-E
Max. Operation Tension IEC 60794–1-2-E1
Crush Test IEC 6079 –1-2-E3
Impact Test IEC 60794–1-2-E4
Repeated Bending IEC 60794–1-2-E6
Torsion Test IEC 60794–1-2-E7
Cable bend IEC 60794–1-2-E11A
Attenuation Coefficient ITU-T G.652
Structural Test IEC-60793-1-20
Environmental Performance
Temperature Cycling IEC 60794–1-2-F1
Water Penetration IEC 60794–1–2-F5B
Filing Compound Flow IEC 60794-1-E14
Packing details:
Cable Type Drum Length(KM) Drum/Carton size (cm) Gross weight/CTN (kgs) KMs/20ft
GYXTW 2~12F 2 70*70*60 160 144
Our advantage:
1.Advanced production and testing equipment
2.Professional manufacturer, 100% tested.
3.Full compliance with ISO 9001:2008 quality management system
4.Our company has experienced professional team
5.Provide reliable solutions and satisfactory services
6.Warmly services with careful attentions.
7.Can provide your specific inquiry within 24 hours.Advanced production and testing equipment
FAQ
1. What are the payment terms that you support?
Usually, we accept T/T, PayPal, Western Union, and Alibaba Trade Assurance. You can select the terms of payment which is more convenient for you.
2. What about the lead time?
Usually, if there's stock, we ship the goods within 3~5 working days after the deposit is confirmed. If it is out of stock, the lead time depends.
3. How about the shipping?
When the package is small, we normally choose FedEx, DHL, TNT, and UPS, and so on, while the goods have high weight and volume, we suggest using air or sea shipment.
4. How can I place an order?
(1) Negotiation is agreed upon for the product price and specifications.
(2) The Proforma invoice will be sent for confirmation.
(3) After the agreement on the proforma invoice, the customer makes the deposit.
(4) Manufacturing will be started as soon as the payment is confirmed by our bank.
(5) Ship out the goods within the agreed delivery deadline.
5. Can you do OEM for us?
Yes. If there is a certain order quantity, we can do OEM including printing, logo, and customized model for you.
6. How about the Warranty?
There are 12 months for the warranty. While the warranty is not responsible for those broken by violence or updated with other brands.


Drawings of Single Mode G657A G652D GYXTW Aerial Outdoor Steel Wire Optical Fiber Cable FTTH GYXTW Fiber Optic Cable

G657A G652D Aerial Steel Wire GYXTW FTTH Fiber Optic Cable
G657A G652D Aerial Steel Wire GYXTW FTTH Fiber Optic Cable
G657A G652D Aerial Steel Wire GYXTW FTTH Fiber Optic Cable
Package of Single Mode G657A G652D GYXTW Aerial Outdoor Steel Wire Optical Fiber Cable FTTH GYXTW Fiber Optic Cable
G657A G652D Aerial Steel Wire GYXTW FTTH Fiber Optic Cable
